ASP.NET countdown timer custom control

ASP.NET countdown timer

Recently I had the need to create an ASP.NET countdown timer for one of my projects.

I needed the ASP.NET countdown timer custom control to:

  • run at client side (java script)
  • have the ability to use the countdown timer several times on the same page with different timers
  • configure the end action for each counter
  • end action for any timer can be: : just stop, refresh page, make an ajax post or partial post.
  • bu used just like any other control, drag n drop to the page, set timer and it’s ready!

you should create a library for the controls, I used ‘CF.Controls’.

The project includes a test project available for download at git: https://github.com/ET-CS/ASP.net-Countdown-Timer-Webform-Control

CountdownTimer.cs

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Configuration;
using System.Linq;
using System.Web;
using System.Web.Security;
using System.Web.UI;
using System.Web.UI.WebControls;
using System.Web.UI.WebControls.WebParts;
using System.Web.UI.HtmlControls;
using System.Xml.Linq;

namespace CF.Controls
{
    public enum EndAction{
    doStop = 0,
    doRefresh = 1,
    doPost = 2,
    doPartialPost = 3}

    /// <summary>
    /// CF.Controls.CountdownTimer Control
    /// </summary>
    [ToolboxData("<{0}:CountdownTimer runat=server />")]
    public class CountdownTimer : ScriptControl, INamingContainer, ICallbackEventHandler
    {

        #region "properties"
            private TimeSpan timelengthvalue;
            [Category("Behavior")]
            [Description("Total TimeSpan to countdown")]
            public TimeSpan TimeLength
            {
                get { return timelengthvalue; }
                set { timelengthvalue = value; }
            }

            private EndAction endactionvalue = CF.Controls.EndAction.doPartialPost;
            [Category("Behavior")]
            [DefaultValue(EndAction.doPartialPost)]
            [Description("End action to perform when time out")]
            public EndAction EndAction
            {
                get { return endactionvalue; }
                set { endactionvalue = value; }
            }

            private bool onlinevalue = true;
            [Category("Behavior")]
            [DefaultValue(true)]
            [Description("Enable or Disable JS timeOut On Countdown")]
            public bool Online
            {
                get { return onlinevalue; }
                set { onlinevalue = value; }
            }

            private string timeoutvalue;
            [Category("Behavior")]
            [DefaultValue("")]
            [UrlProperty]
            [Description("URL to redirect the user, in the event of a membership session timeout")]
            public string TimeoutURL
            {
                get { return timeoutvalue; }
                set { timeoutvalue = value; }
            }
        #endregion

        #region "Callback"
        public void RaiseCallbackEvent(String eventArgument)
        {
            // All we're doing here is resetting the sliding expiration
            // of the forms authentication.  No additional code is needed.
        }

        public String GetCallbackResult()
        {
            // return an emtpy string.  We're not really interested
            // in the return value.
            return String.Empty;
        }
        #endregion

        public CountdownTimer()
        {
            //
            // TODO: Add constructor logic here
            //
        }
        protected override IEnumerable<ScriptDescriptor>
                GetScriptDescriptors()
        {
            ScriptControlDescriptor descriptor = new ScriptControlDescriptor("CF.Controls.CountdownTimer", this.ClientID);

            // Add our TimeLength property to be passed down to the client
            descriptor.AddProperty("timelength", this.timelengthvalue.Ticks);
            descriptor.AddProperty("date", DateTime.UtcNow.Add(this.timelengthvalue));
            descriptor.AddProperty("endaction", this.endactionvalue);
            descriptor.AddProperty("enabled", this.Online);

            yield return descriptor;
        }

        // Generate the script reference
        protected override IEnumerable<ScriptReference>
                GetScriptReferences()
        {
            yield return new ScriptReference("CF.Controls.CountdownTimer.js", this.GetType().Assembly.FullName);
        }

        /// <summary>
        /// returns the number of milliseconds since Jan 1, 1970 (useful for converting C# dates to JS dates)
        /// </summary>
        /// <param name="dt"></param>
        /// <returns></returns>
        Double UnixTicks(DateTime dt) {
            DateTime d1 = new DateTime(1970, 1, 1);
            DateTime d2 = dt.ToUniversalTime();
            TimeSpan ts = new TimeSpan(d2.Ticks - d1.Ticks);
            return ts.TotalMilliseconds;
        }

#region "Render Control"

    void InitialiseControls() {
        Label lbl = new Label();
        lbl.ClientIDMode = ClientIDMode.AutoID;
        lbl.Text = TimeLength.Ticks.ToString();
        this.Controls.Add(lbl);
    }

    protected override void OnPreRender(EventArgs e)
    {
        if (!this.DesignMode)
        {
            if (ScriptManager.GetCurrent(Page) == null)
            {
                throw new HttpException("A ScriptManager control must exist on the current page.");
            }
            InitialiseControls();

            String cbReference =
            Page.ClientScript.GetCallbackEventReference(this,
                                                "arg", "ReceiveServerData", "context");
            String callbackScript;
            callbackScript = "function CallServer(arg, context)" +
                             "{ " + cbReference + ";}";
            Page.ClientScript.RegisterClientScriptBlock(this.GetType(),
                                                        "CallServer", callbackScript, true);
        }
        base.OnPreRender(e);
    }

#endregion

    }
}</pre>
[/code]
<h2>CountdownTimer.js</h2>
[code lang="java"]
<pre>/// <reference name="MicrosoftAjax.js"/>

Type.registerNamespace("CF.Controls");

CF.Controls.CountdownTimer = function (element) {
    //this._element = element; // div control that contains everything
    CF.Controls.CountdownTimer.initializeBase(this, [element]);
    // "private" variables to hold the properties values
    this._timelength = null;
    this._date = null;
    // doStop = 0 , doRefresh = 1 , doPost = 2 , doPartialPost = 3
    this._endaction = 3;
    // 0 false, 1 true
    this._enabled = 1;
    // timer pointer
    this._timerTimeout = null;
    this._starttime = null;
}

CF.Controls.CountdownTimer.prototype = {
    initialize: function () {
        CF.Controls.CountdownTimer.callBaseMethod(this, 'initialize');
        // Add custom initialization here
        var elem = this._element.childNodes;
        for (i = 0; i < elem.length; i++) {
            doc = elem[i];
            var type = doc.type;
        }
        //start timer
        this._starttime = new Date().getTime();
        this._resetTimeout();
        this._timeoutDelegate = Function.createDelegate(this, this.timeout);
        this._timerTimeout = setTimeout(this._timeoutDelegate, 0);
    },
    dispose: function () {
        //Add custom dispose actions here
        this._resetTimeout();
        this._timelength = null;
        CF.Controls.CountdownTimer.callBaseMethod(this, 'dispose');
    },
    // timelength Property Accessors
    get_timelength: function () {
        return this._timelength;
    },
    set_timelength: function (value) {
        this._timelength = value;
        this.raisePropertyChanged('timelength');
    },
    // target date Property Accessors - Depreceated
    get_date: function () {
        return this._date;
    },
    set_date: function (value) {
        this._date = value;
        this.raisePropertyChanged('date');
    },
    // Endaction Property Accessors
    get_endaction: function () {
        return this._endaction;
    },
    set_endaction: function (value) {
        this._endaction = value;
        this.raisePropertyChanged('endaction');
    },
    // Enabled Property Accessors
    get_enabled: function () {
        return this._enabled;
    },
    set_enabled: function (value) {
        this._enabled = value;
        this.raisePropertyChanged('enabled');
    },

    _resetTimeout: function (e) {
        clearTimeout(this._timerTimeout);
        this._timerTimeout = null;
    },

    timeout: function (e) {
        //calculating
        var currentdate = new Date();

        //method 2: calc from time
        var jsticks = this._timelength / 10000;
        var timelength = new Date(jsticks).getTime() - 7200000;
        var difftime = timelength - (currentdate.getTime() - this._starttime - 7200000) - 7200000;

        //check if time is gone - and do events
        if (difftime < -7200000) {
            switch (this._endaction) {
                case 0: break;
                case 1: location.reload(true); break;
                case 2: __doPostBack(); break;
                case 3: __doPostBack(this._element.id); break;
                default:
            }
        }
        else {
            var diff = new Date(difftime);
            //alert(diff);
            var d = getDays(diff.getTime());
            //alert(d);
            var curr_hour
            if (d > 0) {
                curr_hour = formatzero(d * 24 + diff.getHours());
            } else { curr_hour = formatzero(diff.getHours()); }
            var curr_min = formatzero(diff.getMinutes());
            var curr_sec = formatzero(diff.getSeconds());
            //if (curr_hour == 23) { alert(diff.getTime()) };
            var str = curr_hour + ":" + curr_min + ":" + curr_sec;
            //showing
            span = document.getElementById(this._element.id)
            if (span != null) {
                var elem = span.childNodes;
                elem[0].innerHTML = str;
                //timering
                if (this._enabled == 1) {
                    this._timeoutDelegate = Function.createDelegate(this, this.timeout);
                    this._timerTimeout = setTimeout(this._timeoutDelegate, 350);
                    //setTimeout("displayCountdown('" + obj + "','" + desttime + "','" + time + "','" + start + "'," + endaction + "," + online + ")", 900);
                }
            };
        }
    }
}

function getDays(d)
{
    var ONE_DAY = 1000 * 60 * 60 * 24;
    return Math.round(d/ONE_DAY);
}

function formatzero(obj)
{
    return ((obj) > 9) ? (obj) : '0' + (obj);
}

function ReceiveServerData(rValue) {}

CF.Controls.CountdownTimer.registerClass('CF.Controls.CountdownTimer', Sys.UI.Control);

if (typeof(Sys) !== 'undefined') Sys.Application.notifyScriptLoaded();
[/code]</pre>
The project includes a test project available for download at git: <a title="https://github.com/ET-CS/ASP.net-Countdown-Timer-Webform-Control" href="https://github.com/ET-CS/ASP.net-Countdown-Timer-Webform-Control" target="_blank">https://github.com/ET-CS/ASP.net-Countdown-Timer-Webform-Control</a>
<h2>Using CountdownTimer</h2>
Using the custom control inside .aspx page
to use this custom control, A ScriptManager control must exist on the page.
in your .aspx page you need to declare it:

[code parse="no"]<%@ Register Assembly="CF.Controls" Namespace="CF.Controls" TagPrefix="cc1" %>
<cc1:CountdownTimer ID="CountdownTimer1" runat="server" EndAction="doRefresh" />
using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Configuration;
using System.Linq;
using System.Web;
using System.Web.Security;
using System.Web.UI;
using System.Web.UI.WebControls;
using System.Web.UI.WebControls.WebParts;
using System.Web.UI.HtmlControls;
using System.Xml.Linq;

namespace CF.Controls
{
    public enum EndAction{
    doStop = 0,
    doRefresh = 1,
    doPost = 2,
    doPartialPost = 3}

    /// <summary>
    /// CF.Controls.CountdownTimer Control
    /// </summary>
    [ToolboxData("<{0}:CountdownTimer runat=server />")]
    public class CountdownTimer : ScriptControl, INamingContainer, ICallbackEventHandler
    {

        #region "properties"
            private TimeSpan timelengthvalue;
            [Category("Behavior")]
            [Description("Total TimeSpan to countdown")]
            public TimeSpan TimeLength
            {
                get { return timelengthvalue; }
                set { timelengthvalue = value; }
            }

            private EndAction endactionvalue = CF.Controls.EndAction.doPartialPost;
            [Category("Behavior")]
            [DefaultValue(EndAction.doPartialPost)]
            [Description("End action to perform when time out")]
            public EndAction EndAction
            {
                get { return endactionvalue; }
                set { endactionvalue = value; }
            }

            private bool onlinevalue = true;
            [Category("Behavior")]
            [DefaultValue(true)]
            [Description("Enable or Disable JS timeOut On Countdown")]
            public bool Online
            {
                get { return onlinevalue; }
                set { onlinevalue = value; }
            }

            private string timeoutvalue;
            [Category("Behavior")]
            [DefaultValue("")]
            [UrlProperty]
            [Description("URL to redirect the user, in the event of a membership session timeout")]
            public string TimeoutURL
            {
                get { return timeoutvalue; }
                set { timeoutvalue = value; }
            }
        #endregion

        #region "Callback"
        public void RaiseCallbackEvent(String eventArgument)
        {
            // All we're doing here is resetting the sliding expiration
            // of the forms authentication.  No additional code is needed.
        }

        public String GetCallbackResult()
        {
            // return an emtpy string.  We're not really interested
            // in the return value.
            return String.Empty;
        }
        #endregion

        public CountdownTimer()
        {
            //
            // TODO: Add constructor logic here
            //
        }
        protected override IEnumerable<ScriptDescriptor>
                GetScriptDescriptors()
        {
            ScriptControlDescriptor descriptor = new ScriptControlDescriptor("CF.Controls.CountdownTimer", this.ClientID);

            // Add our TimeLength property to be passed down to the client
            descriptor.AddProperty("timelength", this.timelengthvalue.Ticks);
            descriptor.AddProperty("date", DateTime.UtcNow.Add(this.timelengthvalue));
            descriptor.AddProperty("endaction", this.endactionvalue);
            descriptor.AddProperty("enabled", this.Online);

            yield return descriptor;
        }

        // Generate the script reference
        protected override IEnumerable<ScriptReference>
                GetScriptReferences()
        {
            yield return new ScriptReference("CF.Controls.CountdownTimer.js", this.GetType().Assembly.FullName);
        }

        /// <summary>
        /// returns the number of milliseconds since Jan 1, 1970 (useful for converting C# dates to JS dates)
        /// </summary>
        /// <param name="dt"></param>
        /// <returns></returns>
        Double UnixTicks(DateTime dt) {
            DateTime d1 = new DateTime(1970, 1, 1);
            DateTime d2 = dt.ToUniversalTime();
            TimeSpan ts = new TimeSpan(d2.Ticks - d1.Ticks);
            return ts.TotalMilliseconds;
        }

#region "Render Control"

    void InitialiseControls() {
        Label lbl = new Label();
        lbl.ClientIDMode = ClientIDMode.AutoID;
        lbl.Text = TimeLength.Ticks.ToString();
        this.Controls.Add(lbl);
    }

    protected override void OnPreRender(EventArgs e)
    {
        if (!this.DesignMode)
        {
            if (ScriptManager.GetCurrent(Page) == null)
            {
                throw new HttpException("A ScriptManager control must exist on the current page.");
            }
            InitialiseControls();

            String cbReference =
            Page.ClientScript.GetCallbackEventReference(this,
                                                "arg", "ReceiveServerData", "context");
            String callbackScript;
            callbackScript = "function CallServer(arg, context)" +
                             "{ " + cbReference + ";}";
            Page.ClientScript.RegisterClientScriptBlock(this.GetType(),
                                                        "CallServer", callbackScript, true);
        }
        base.OnPreRender(e);
    }

#endregion

    }
}</pre>
[/code]
<h2>CountdownTimer.js</h2>
[code lang="java"]
<pre>/// <reference name="MicrosoftAjax.js"/>

Type.registerNamespace("CF.Controls");

CF.Controls.CountdownTimer = function (element) {
    //this._element = element; // div control that contains everything
    CF.Controls.CountdownTimer.initializeBase(this, [element]);
    // "private" variables to hold the properties values
    this._timelength = null;
    this._date = null;
    // doStop = 0 , doRefresh = 1 , doPost = 2 , doPartialPost = 3
    this._endaction = 3;
    // 0 false, 1 true
    this._enabled = 1;
    // timer pointer
    this._timerTimeout = null;
    this._starttime = null;
}

CF.Controls.CountdownTimer.prototype = {
    initialize: function () {
        CF.Controls.CountdownTimer.callBaseMethod(this, 'initialize');
        // Add custom initialization here
        var elem = this._element.childNodes;
        for (i = 0; i < elem.length; i++) {
            doc = elem[i];
            var type = doc.type;
        }
        //start timer
        this._starttime = new Date().getTime();
        this._resetTimeout();
        this._timeoutDelegate = Function.createDelegate(this, this.timeout);
        this._timerTimeout = setTimeout(this._timeoutDelegate, 0);
    },
    dispose: function () {
        //Add custom dispose actions here
        this._resetTimeout();
        this._timelength = null;
        CF.Controls.CountdownTimer.callBaseMethod(this, 'dispose');
    },
    // timelength Property Accessors
    get_timelength: function () {
        return this._timelength;
    },
    set_timelength: function (value) {
        this._timelength = value;
        this.raisePropertyChanged('timelength');
    },
    // target date Property Accessors - Depreceated
    get_date: function () {
        return this._date;
    },
    set_date: function (value) {
        this._date = value;
        this.raisePropertyChanged('date');
    },
    // Endaction Property Accessors
    get_endaction: function () {
        return this._endaction;
    },
    set_endaction: function (value) {
        this._endaction = value;
        this.raisePropertyChanged('endaction');
    },
    // Enabled Property Accessors
    get_enabled: function () {
        return this._enabled;
    },
    set_enabled: function (value) {
        this._enabled = value;
        this.raisePropertyChanged('enabled');
    },

    _resetTimeout: function (e) {
        clearTimeout(this._timerTimeout);
        this._timerTimeout = null;
    },

    timeout: function (e) {
        //calculating
        var currentdate = new Date();

        //method 2: calc from time
        var jsticks = this._timelength / 10000;
        var timelength = new Date(jsticks).getTime() - 7200000;
        var difftime = timelength - (currentdate.getTime() - this._starttime - 7200000) - 7200000;

        //check if time is gone - and do events
        if (difftime < -7200000) {
            switch (this._endaction) {
                case 0: break;
                case 1: location.reload(true); break;
                case 2: __doPostBack(); break;
                case 3: __doPostBack(this._element.id); break;
                default:
            }
        }
        else {
            var diff = new Date(difftime);
            //alert(diff);
            var d = getDays(diff.getTime());
            //alert(d);
            var curr_hour
            if (d > 0) {
                curr_hour = formatzero(d * 24 + diff.getHours());
            } else { curr_hour = formatzero(diff.getHours()); }
            var curr_min = formatzero(diff.getMinutes());
            var curr_sec = formatzero(diff.getSeconds());
            //if (curr_hour == 23) { alert(diff.getTime()) };
            var str = curr_hour + ":" + curr_min + ":" + curr_sec;
            //showing
            span = document.getElementById(this._element.id)
            if (span != null) {
                var elem = span.childNodes;
                elem[0].innerHTML = str;
                //timering
                if (this._enabled == 1) {
                    this._timeoutDelegate = Function.createDelegate(this, this.timeout);
                    this._timerTimeout = setTimeout(this._timeoutDelegate, 350);
                    //setTimeout("displayCountdown('" + obj + "','" + desttime + "','" + time + "','" + start + "'," + endaction + "," + online + ")", 900);
                }
            };
        }
    }
}

function getDays(d)
{
    var ONE_DAY = 1000 * 60 * 60 * 24;
    return Math.round(d/ONE_DAY);
}

function formatzero(obj)
{
    return ((obj) > 9) ? (obj) : '0' + (obj);
}

function ReceiveServerData(rValue) {}

CF.Controls.CountdownTimer.registerClass('CF.Controls.CountdownTimer', Sys.UI.Control);

if (typeof(Sys) !== 'undefined') Sys.Application.notifyScriptLoaded();
[/code]</pre>
The project includes a test project available for download at git: <a title="https://github.com/ET-CS/ASP.net-Countdown-Timer-Webform-Control" href="https://github.com/ET-CS/ASP.net-Countdown-Timer-Webform-Control" target="_blank">https://github.com/ET-CS/ASP.net-Countdown-Timer-Webform-Control</a>
<h2>Using CountdownTimer</h2>
Using the custom control inside .aspx page
to use this custom control, A ScriptManager control must exist on the page.
in your .aspx page you need to declare it:

[code parse="no"]<%@ Register Assembly="CF.Controls" Namespace="CF.Controls" TagPrefix="cc1" %>
<cc1:CountdownTimer ID="CountdownTimer1" runat="server" EndAction="doRefresh" />

and add a counter using: set timer from code-behind is easy too:

1
CountdownTimer1.TimeLength = new TimeSpan(2, 14, 18);
CountdownTimer1.TimeLength = new TimeSpan(2, 14, 18);



you can set the EndAction (CountdownTimer1.EndAction=) to either doStop, doRefresh, doPost or doPartialPost (Default).

  • doStop – Stop at the end
  • doRefresh – Refresh at the end
  • doPost – Do full post
  • doPartialPost (Default) – Do partial post (using the microsoft ajax framwork)



Set the .online parameter to ‘disabled’ to disable countdown.

A ScriptManager control must exist on the current page.

1 thought on “ASP.NET countdown timer custom control

Leave a Reply

Your email address will not be published. Required fields are marked *

*

This site uses Akismet to reduce spam. Learn how your comment data is processed.
